PC-Duo Master Guide
110
Tool bar options
Table below summarizes the functions of icons available on the tool bar for the Master
Connection window:
Icon
Function
Start remote control session
Start file transfer session
Start remote printing session
Start remote management session
Disconnect from Host
Displays the screen output from the
remote Host computer using the entire
monitor screen on the local computer.
To return to the local computer display,
click the Full Screen button on the
floating palette, or press F11 in the
Master Connection window.
Specifies that one pixel of the Host
computer display corresponds to exactly
one pixel on the display of the local
computer.
Scales the image of the Host computer
display to fit the size of the connection
window.
Sends Ctrl-Alt-Del keyboard
combination to remote Host
Sends a predefined key combination to the
Host computer as though it were entered on
the keyboard of the remote Host computer
when you are connected to it for remote
control. This is useful for sending special key
combinations such as CTRL-ALT-DEL.
Gives keyboard and mouse control of the
Host computer to the remote user of a
Gateway-managed connection.
Toggles whether the Master sends
keystrokes, mouse movements, or mouse
selections to the remote Host computer from
the Remote Control tab of the Master
Connection window. When you select View
